LEVENHUK MED D35T DIGITAL TRINOCULAR MICROSCOPE

LEVENHUK MED D35T DIGITAL TRINOCULAR MICROSCOPE

Features:

• Magnification: 40x to 1000x
• Trinocular head with wide-field eyepieces
• Plan achromatic optics with an anti-fungal coating
• Halogen light with adjustable brightness
• Setting up Köhler illumination is available
• Powered by an AC power supply
• 10MP digital camera is included

The Levenhuk MED D35T Digital Microscope combines the capabilities of a classic biological model and a microscope for taking digital photos and videos. It comes with a 10MP camera that is connected to a computer and allows for observing an image on its screen in real-time mode. This microscope is excellent for a university department, research center, or clinical and diagnostics laboratory.

The microscopes in the Levenhuk MED 35 series are equipped with an infinity-corrected optical system that is used in professional and high-class microscopes. This system includes Infinity PlanAchromat objectives and allows for obtaining clear, high contrast images with high level of flatness.

One of the most important features of an infinity-corrected optical system is that it allows for installing any additional parts in the optical path between objective lenses and an ocular tube. The additional parts include polarizers, epi-fluorescence light, and DIC prisms that feature minimal focus deviations and correct aberrations. All in all, modular design and simple operation make Levenhuk MED 35 optimal microscopes for using in different kinds of microscopy and working in hematological, histological, microbiological, and other laboratories.

A trinocular head has a binocular visual unit and a vertical tube inclined at 30° for installing a digital camera in it. The head is 360° rotatable, which is convenient if the sample should be observed by several researchers. If you move an entire microscope, you can accidentally change the optics settings. You only need to turn the head of Levenhuk MED D35T to let another person observe.

The image is formed by wide-field 10x eyepieces with diopter adjustment and plan achromatic objectives with various magnification. Plan achromatic optics flatten the field of view, reduce chromatic aberrations, and improve color rendering. You can conduct highly detailed observations at magnifications of 40x to 1000x. The objective lenses with 40x, 60x, and 100x magnifications are equipped with spring-loaded protective frames; the 100x objective lens is used for oil immersion observations. The sharpness is adjusted with the coarse and fine focusing adjustment knobs.

The stage is moveable along two axes and equipped with a mechanical scale. Underneath, there is a halogen light (30W) with adjustable brightness. An Abbe condenser with an iris diaphragm is used for directing an optical beam. There is a special holder for putting optical filters, which enhance the image sharpness and contrast. Three optical filters are included in the kit. You can also set up Köhler illumination. The light is powered by an AC power supply.

A 10MP sensor in a digital camera (included in the kit) allows for obtaining high-resolution pictures. Moreover, recording smooth videos with high frame rate is available. Special software (on an included CD) allows for the simple processing of recorded images. A digital camera is powered and connected to a computer via a USB cable.

Caution: Please refer to the specifications table for the correct mains voltage and never attempt to plug a 110V device into 220V outlet and vice versa without using a converter. Remember that mains voltage in the U.S. and Canada is 110V and 220–240V in most European countries.
